Description
CONTROL TEMPERATURE SYSTEM
| Range | -100 °C to 1100 °C with CryoCooler Ambient to 1100°C (without CryoCooler) |
| Selection | Digitally set, 1 °C increments |
| Ramp Rates | Up to 50 °C per minute within -70 to 500 °C Up to 30 °C per minute from 500 to 750 °C Up to 10 °C per minute from 750 to 1100 °C |
GASES
| Loop (Analysis) | Hydrogen, Monoxide, Oxygen, Nitrous Oxide, Ammonia |
| Carrier | Helium, Argon, and other gases |
| Preparation | Hydrogen, Oxygen, Helium, Argon and others |
GAS FLOW RATE
| Three Mass Flow Controllers (MFCs) | |
| Manual Control | 10 to 100 cm3/min* |
| Automatic Analysis | 10 to 75 cm3/min Pressure Specifications Ambient to 1000 psia accurate to 0.5% of full scale |
GAS DELIVERY
| Inlet Ports | 4 each for preparation gas, carrier gas and loop (analysis) gas |
| Temperature Control | Internal gas lines and valves heated up to 150 °C |
* Rate for Hydrogen; other gases have different range.
